Dehydration Machine for Oily Sludge Treatment

  • Dehydration Machine for Oily Sludge Treatment
  • Dehydration Machine for Oily Sludge Treatment
  • Dehydration Machine for Oily Sludge Treatment
  • Dehydration Machine for Oily Sludge Treatment

Dehydration Machine for Oily Sludge Treatment

    Unit Price: 5000 USD
    Min. Order: 1 Set/Sets
    Productivity: 100/month
    Brand: shenhongfa
    Transportation: Ocean,Land
    Place of Origin: china
    Certificate: ce rohs
    HS Code: 8421291090

Product Description

Dehydration Machine for Oily Sludge Treatment

Product Description
Multi-disc screw press (Hereinafter referred to as MDS) is a new generation of sludge dewatering machine, a screw type sludge dewatering press having more advantages than belt press, centrifuge, plate-and-frame filter press, etc. It features clog-free, wide range of applications, power saving, fully automatic control, low running cost, high resistance to oily sludge, simple operation & maintenance, small footprint, etc. MDS can be widely used in Municipal sewage, food, slaughtering breeding, printing and dyeing, oil chemical industry, paper making, leather, pharmaceutical and other industries of sludge dewatering.Meanwhile, the unique self-cleaning mechanism and stainless steel structure enables MDS to be ideal to dewater oily sludge, which easily causes clogging and is difficult to treat with other types of dewatering equipment.

Specifications


Main Parameters
Capacity DS-kg/hr 180-300 DS-kg/hr
Size mm L 3605×W1690×H1600
Power kW 1.95


Motor
Gearbox Brand SEW, BAUER,
SUMITOMO, NISSEI
Protection Certificates & IP UL,CE, Water proof(IP65) CCC
Screw Shaft Treatment SUS316L, Tungsten carbide coating


Control Cabinet
Electrical Components Brand Schneider, Omron, Siemens
Solenoid Valve Brand US, ASCO
Spray System Brand Japan Origin, H.IKEUCHI

Model Selection



Model
WAS Sludge
& Chemical Precipitated Sludge
(Thin Sludge)


Dissolved Air Flotation Sludge
Mixed Raw Sludge
Aerobic Digested Sludge
& Sewage Sludge
Sludge Concentration (TS)

0.2%


1%


2%


5%


3%
MDS 051 ~0.4 kg-DS/hr
(0.2 m³/hr)
~0.6 kg-DS/hr
(0.06 m³/hr)
~2 kg-DS/hr
(0.1 m³/hr)
~4 kg-DS/hr
(0.08 m³/hr)
~5 kg-DS/hr
(0.16 m³/hr)
MDS 101 ~2 kg-DS/hr
(1.0 m³/hr)
~3 kg-DS/hr
(0.3 m³/hr)
~5 kg-DS/hr
(0.25 m³/hr)
~10 kg-DS/hr
(0.2 m³/hr)
~13 kg-DS/hr
(0.43 m³/hr)
MDS 131 ~4 kg-DS/hr
(2.0 m³/hr)
~6 kg-DS/hr
(0.6 m³/hr)
~10 kg-DS/hr
(0.5 m³/hr)
~20 kg-DS/hr
(0.4 m³/hr)
~26 kg-DS/hr
(0.87 m³/hr)
MDS 132 ~8 kg-DS/hr
(4.0 m³/hr)
~12 kg-DS/hr
(1.2 m³/hr)
~20 kg-DS/hr
(1.0 m³/hr)
~40 kg-DS/hr
(0.8 m³/hr)
~52 kg-DS/hr
(1.73 m³/hr)
MDS 202 ~16 kg-DS/hr
(8.0 m³/hr)
~24 kg-DS/hr
(2.4 m³/hr)
~40 kg-DS/hr
(2.0 m³/hr)
~80 kg-DS/hr
(1.6 m³/hr)
~104 kg-DS/hr
(3.47 m³/hr)
MDS 311 ~20 kg-DS/hr
(10 m³/hr)
~30 kg-DS/hr
(3.0 m³/hr)
~50 kg-DS/hr
(2.5 m³/hr)
~100 kg-DS/hr
(2.0 m³/hr)
~130 kg-DS/hr
(4.33 m³/hr)
MDS 312 ~40 kg-DS/hr
(20 m³/hr)
~60 kg-DS/hr
(6.0 m³/hr)
~100 kg-DS/hr
(5.0 m³/hr)
~200 kg-DS/hr
(4.0 m³/hr)
~260 kg-DS/hr
(8.67 m³/hr)
MDS 313 ~60 kg-DS/hr
(30 m³/hr)
~90 kg-DS/hr
(9.0 m³/hr)
~150 kg-DS/hr
(7.5 m³/hr)
~300 kg-DS/hr
(6.0 m³/hr)
~390 kg-DS/hr
(13 m³/hr)
MDS 412 ~80 kg-DS/hr
(40 m³/hr)
~120 kg-DS/hr
(12 m³/hr)
~200 kg-DS/hr
(10 m³/hr)
~400 kg-DS/hr
(8.0 m³/hr)
~520 kg-DS/hr
(17.3 m³/hr)
MDS 413 ~120 kg-DS/hr
(60 m³/hr)
~180 kg-DS/hr
(18 m³/hr)
~300 kg-DS/hr
(15 m³/hr)
~600 kg-DS/hr
(12 m³/hr)
~780 kg-DS/hr
(26 m³/hr)

01 5 Png01 41616663032 101 3 Png
Our Advantages


(1) Hongfa sludge dewatering machine is of unique dewatering structure with fixed and moving rings. It has many advantages over other dewatering machines such as plate and frame filter press, belt filter press and decanter centrifuge, especially for power and rinsing water consumption and labor cost saving. Below is a comparison table among them.



(2) High resistence to oily sludge
The self-cleaning mechanism and stainless steel structure enables MDS to be ideal to dewater oily sludge, which easily cause clogging and is difficult to treat with other types of dewatering equipment like belt filter press.
Dehydration Machine for Oily Sludge Treatment (MDS101)


(3) Clog-free -- saving rinsing water -- saving cost
Due to the rotation of helical axis, the moving rings begin detaching from the fixed rings while continuously starting the
self-cleaning process. As a result, the ubiquitous clogging is avoided with the unique structure. Therefore, it can handle oily sludge without any trouble while separating the water from the sludge easily. In addition, there is no need to add large quantity of rinsing water, thus MDS can saving the cost.
Dehydration Machine for Oily Sludge Treatment (MDS101)



(4) Saving energy -- low power consumption
MDS works by the machine's internal pressure and needs no large scale integrations like rollers. It saves energy and water and has very minimal noise because of low running speed (2-4 r/min). The average unit power consumption is only 0.1-0.01 kwh/kg-Ds (1/8 of Belt Press and 1/20 of Centrifuge).
Dehydration Machine for Oily Sludge Treatment (MDS101)
(5) Fully automatic control -- saving labor cost
There are no easily blocked pieces such as belt and filtration pore in MDS. Combining with the auto control system, the machine runs very safely and simply and can be programmed according to the requirement of the users. It can operate automatically for 24 hours, unmanned.
Dehydration Machine for Oily Sludge Treatment (MDS101)



(6) Small footprint -- saving the construction investment of dewatering room
With the smart design, MDS dewatering press can be installed in places where placement would not be possible with other technologies.
Dehydration Machine for Oily Sludge Treatment (MDS101)


(7) No thickeners -- saving the capital investment and costs on other auxiliary equipment
MDS can treat sludge in aeration tank and secondary sedimentation tank without setting sludge thickeners. Therefore, this can decrease the total investment and costs on mixers, air compressors, flushing pumps and other auxiliary equipment.
Dehydration Machine for Oily Sludge Treatment (MDS101)


Dewater Principle


The initial section of dewatering drum is the Thickening Zone,where the solid-liquid separating process takes place and where the filtrate will also be discharged. The pitch of the screw and the gaps between the rings decrease at the end of dewatering drum, hence increasing its internal pressure. At the end, the End Plate further increases the pressure, so as to discharge dry sludge cake.The initial section of dewatering drum is the Thickening Zone,where the solid-liquid separating process takes place and where the filtrate will also be discharged. The pitch of the screw and the gaps between the rings decrease at the end of dewatering drum, hence increasing its internal pressure. At the end, the End Plate further increases the pressure, so as to discharge dry sludge cake.
Dehydration Machine for Oily Sludge Treatment (MDS101)



Product Display
Dehydration Machine for Oily Sludge Treatment (MDS101)
